12.2.2.4 Assigning function keys on the DECT 800 handset
You can edit the following settings:
*Assigning contacts to name keys
*Copying function key assignments from another DECT handset

Do not assign the function keys directly on the device. Otherwise, configuration errors may occur.
The configuration may only be done via Swyx Control Center.


The user settings for a DECT handset can only be edited if the handset is assigned to a user.

To assign function keys as name keys
1 Select Devices | DECT.
2 Select the Tab Assigned handsets.
3 In the line of the corresponding Handset, click on .
*The configuration wizard appears Edit DECT handset for user....
Label
Explanation
Button no.
Number of the assignable button in accordance with the numbering accepted.
Labelling
Name that appears in the button list.
Function
If you select Speed dial, the appropriate input fields Index and Number as well as the Edit option are activated, see To assign a Speed Dial.
4 Click on Save all.
*The changes are saved and updated on the DECT handset.
To assign a Speed Dial
1 Select Devices | DECT.
2 Select the Tab Assigned handsets.
3 In the line of the corresponding Handset, click on .
*The configuration wizard appears Edit DECT handset for user....
4 Select the Speed dial option from the dropdown list.
5 Select the number for the intended speed dial under Index.

The "Index" number is used to assign the name key in the user account and does not determine the order of the name keys on the handset.

6 Click on in the line of the speed dial selected.

The settings for the selectable options and the User picture are only relevant for SwyxIt! or SwyxPhone Lxxx.

Label
Explanation
Labelling
Enter the display name for the appropriate speed dial.
Number/URI
Enter the number which is selected via the speed dial. The corresponding labelling is entered automatically.
Or:
Select a User from the phonebook via the button.
Dialing options
Activate the appropriate options, if applicable:
Immediate Dial
Confirmation of the speed dial starts the call.
Deleting the display before dialing
The display is deleted before dialing.
Intercom Connection
Confirmation of the speed dial starts intercom connection.
User’s picture
Select whether a User picture will be displayed and upload a file from your file system, if applicable.
Automatic
The User picture is ´transmitted by SwyxServer.
To copy the assignment of name keys from another handset
1 Select Devices | DECT.
2 Select the Tab Assigned handsets.
3 In the line of the corresponding Handset, click on .
*The configuration wizard appears Edit DECT handset for user....
4 Click on Copy settings from another DECT handset.
5 Activate the checkbox in the line of the desired handset.
6 Click on Copy.
7 Click on Save all.
*The function key assignment is copied and saved.
